Our entrance door range covers DoorCo composite slabs and Eurocell uPVC front doors, manufactured in-house at our Morley facility.
Aluminium bifold doors, delivered installation-ready
Browse the spec sheets, colour options and brochure downloads below. Everything trade installers need to quote, order and fit our aluminium bifolds with confidence.
- Details and features
- Specifications
- Glazing and Security
- Colours
- Downloads
Our bifold door specifications, based on our super-slim model
If you have any questions, feel free to get in touch.
Contact Us| Specification | Detail |
|---|---|
| Frame width | 48.5mm (55mm for sashes over 2600mm) |
| Frame interlock (with 10mm gasket) | 107mm sightline |
| Frame depth | 73mm |
| Maximum sash height | 3000mm |
| Sash width | 700mm - 1200mm |
| Panel configurations | 2 to 14 sashes |
| Traffic door | Standard on odd panel configurations |
| Glazing | 28mm LowE toughened double glazing (44mm triple available) |
| U-values | Around 1.4 (double) / 0.6 (triple glazed unit) |
| Locking | 5-point system, Secure by Design, 3-star Ultion cylinder option |
| Cills | 90mm stub, 150mm standard, 190mm and 230mm |
| Standard colours | Anthracite Grey, Black, White |
| Accreditation | PAS 24 (with glazing and cylinder upgrade) |
Glazing and security specification
Our bifolds come fitted with LowE toughened double glazing as standard, delivering U-Values around 1.4 U and reduced heating bills. A 5-point locking system, Secure by Design hardware and optional 3-star Ultion cylinders meet PAS 24 standards, keeping intruders out and giving installers peace of mind.
Contact Us
Three stocked frame colours
We hold Anthracite Grey, Black and White in stock to cut lead times, with deliveries possible within two weeks. Dual colour finishes and the full RAL range are available on request.
Contact Us
Brochures and technical downloads
Download the full brochure, colour chart and technical drawings to share with your customers. Everything you need to specify, quote and order our aluminium bifold doors.
Contact UsWhy specify our aluminium bifolds?
Every bifold is bespoke manufactured to your sizes, with engineering grade stainless steel rollers, high performance weather seals and toughened LowE glass sourced from trusted UK suppliers. Frames are powder coated to marine grade for long-term durability in all conditions.
Security is built in from the ground up. A 5-point locking system, Secure by Design hardware and 3-star door barrels protect against intruders, with PAS 24 certification available. Handles come in anthracite, black, white, chrome or satin aluminium to suit any project.
Why partner with Alpine?
We’ve been manufacturing from our Morley site for over 20 years, with Peter, our director, bringing close to 50 years of hands-on industry experience. Combined with business partner Richard, that’s more than 80 years of trade expertise behind every order.
As a family-run manufacturer, we offer free delivery across Leeds, same-day responses to trade enquiries and 24-hour quote turnaround. From single doors to large volume jobs, every bifold is built to your spec with the flexibility smaller installers need.
Bifold door FAQs
Common trade questions about our aluminium bifold doors, lead times and specifications. Speak to our expert team on 0113 531 3148 for anything not covered below.
Contact UsWe manufacture bifold doors in aluminium predominantly. The JA-48 system delivers slimmer sightlines than uPVC equivalents, so aluminium is the right choice to get the most out of bifolds.
We hold considerable stock of standard colours, so glazed JA-48 bifolds can be delivered in as little as two weeks from order.
We offer free delivery across Leeds and supply trade customers throughout Yorkshire, including Harrogate, York, Sheffield and Selby. Orders outside our core region are accepted, just get in touch.
How we work with the trade
Our Process
Initial quote
Send us your sizes online or over the phone. We turn most trade quotes around within 24 hours, and there is no obligation to proceed.
Conversation
We talk through the priorities for you or your client, be it design, thermal performance, security, colour finish, glazing, or locking.
Manufacturing
We manufacture in-house at our Morley facility using Eurocell uPVC profiles, DoorCo composite slabs and Alunet aluminium systems. Typical lead time is two weeks.
Bespoke build, testing and supply
Every frame is made to your exact sizes and quality-checked before despatch. Supply only as standard, full installation available on request.
